Specification
|
|
|
|
Diameter
|
25-89mm
|
|
|
Length
|
100-2000mm
|
|
|
Tube
|
45# steel(GB) equal to C45，201SUS,304SUS
|
|
|
Shaft
|
45# steel(GB) equal to C45，201SUS,304SUS
|
|
|
Bearing
|
Single & Double Row Deep Groove Ball Bearing 2RZ&2Z wigh C3 clearance
|
|
|
Grease
|
Lithium soap type grease,grease retaining inner seal with Multi-stage Labyrinth and Retention Cap with Outboard Rubbing Flinger Seal
|
|
|
Lubrication
|
Grease is Lithium soap type grease with Rust Inhibitors
|
|
|
Welding
|
Mixed gas shielded arc welding end
|
|
|
Painting
|
Ordinary painting, hot galvanized painting, electric static spraying painting, baked painting
|
|
|
Standard Diameter(mm)
|
Roller Thickness (mm)
|
Roller Length
(mm)
|
Shaft Diameter
(Min-Max)
|
Tube Material
|
|
φ25
|
T=0.8/1.0/1.2
|
100-2000
|
φ8
|
Carbon Steel Stainless Steel |
|
φ38
|
T=1.0/1.2/1.5
|
100-2000
|
φ12
|
|
|
φ50
|
T=1.0/1.2/1.5/2.0
|
100-2000
|
φ12/φ15
|
|
|
φ60
|
T=1.2/1.5/2.0
|
100-2000
|
φ12/φ15
|
|
|
φ76
|
T=1.5/2.0/3.0
|
100-2000
|
φ12/φ15/φ20
|
|
|
φ89
|
T=2.0/2.5/3.0
|
100-2000
|
φ20
|
